Mondraker Prime / eBike
If you want to enter the world of light ebikes with a powerful motor, this is the bike for you. With its optimized Bosch Performance Line CX Cruise GEN4 motor offering ideal pedaling assistance, you can use the wireless Mini Remote, the System Controller and the Kiox 300 to manage the option modes and the range of the battery. Limitless and offering a world of possibilities, we’ve adapted our FORWARD GEOMETRY so that you can spend as many hours as you wish on the PRIME 29. Standout characteristics are comfort and light weight, which combine to let you have loads of fun on any type of terrain. Its RockShox Recon Silver RL fork with 120mm of travel opens up your options for adventure and will let you challenge yourself wherever you choose to ride.
Specifications subject to change without notification
01. FRAME Prime Xtralite 6061 Full Butted Alloy, Forward Geometry, intenal removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor
02. FORK RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 32mm steel stanchions, 42mm offset. Settings: compression adjustment at low-speed to lock, rebo
03. HEADSET Onoff Saturn tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41x30.2x7x45 degreex45 degree, bottom 51.9x40x8x45 degreex45 degree
04. STEM Onoff Sulfur FG 30mm 0 degree, 6061 forged alloy, 31.8mm barbore
05. HANDLEBAR Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 degree backsweep, 5 degree upsweep, 31.8mm barbore
06. GRIPS Onoff Twin, 1lock-on, 135mm
07. SEATPOST Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm
08. SADDLE MDK ebike black
09. FRONT BRAKE Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad
10. REAR BRAKE Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad
11. BRAKE LEVER Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings
12. FRONT HUB Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts
13. REAR HUB Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts
14. FRONT TIRE Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
15. REAR TIRE Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead
16. CRANKSET Race Face Aeffect ebike, 165mm
17. RINGS Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
18. PEDALS N/A
19. CHAIN Sram SX Eagle, 12s, Powerlock
20. REAR DERAILLEUR Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
21. CASSETTE Sram PG-1210, 11-50T, 12s
22. MOTOR Bosch Performance Line CX Cruise (25Km/h) GEN4
23. BATTERY Bosch Powertube 625Wh
24. DISPLAY Bosch Kiox 300 / Bosch Led Remote
25. DERAILLEUR HANGER Mondraker M068
26. SIZES S: 390mm / M: 430mm / L: 470mm / XL: 510mm
