The mountain bike experience starts here. With a redesigned frame that’s now lighter and more durable, along with a smooth-riding suspension fork, thru-axle hubs*, and a 1x drivetrain*, this aluminium hardtail is everything an aspiring MTB rider needs to evolve and advance. *on select models
Features
Modern MTB Design: Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow.*on select models
Off-Road Control: New geometry is optimised for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size and model. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size and model. All models have clearance for high-volume tyres (up to 2.4-inch) for traction and grip on technical terrain.
Light and Durable: All-new ALUXX aluminium frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.
Specifications
Sizes: 27.5: XS, S, 29: S, M, L, XL
Colours: Radiant Orange, Black
Frame: ALUXX-grade aluminium, disc
Fork: SR Suntour XCE 28, coil spring, QR, steel steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M: 100mm travel (29), L: 100mm travel (29) XL: 100mm travel (29)
Shock: N/A
Handlebar: Giant Connect Trail, 31.8mm
Grips: Giant Sole-O
Stem: Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (29) L: 70mm (29) XL: 80mm (29)
Seatpost: Giant Sport, 30.9mm
Saddle: Giant ErgoContact Trail
Pedals: MTB caged
Shifters: microSHIFT Acolyte, 1x8
Front Derailleur: N/A
Rear Derailleur: microSHIFT Acolyte, M5185M w/clutch
Brakes: TKB-172, mechanical [F] 160mm, [R] 160mm rotors
Brake Levers: Alloy
Cassette: microSHIFT H083, 12x46
Chain: KMC 8.3
Crankset: ProWheel Forged, 32t XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (29) L: 170mm (29) XL: 175mm (29)
Bottom Bracket: Cartridge
Rims: Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
Hubs: Alloy, sealed
Spokes: Stainless, 14g
Tires: Maxxis Ikon 27.5" or 29x2.2", wire bead
Extras: 2.4" max tyre size, 32t max chainring size
Mfr Claimed Weight
TBC
